Connectthetemperatureprobeintotheinstrumentviathetempsocket.
Usingtheinstrumenttomeasuretimberyoucanobtaintheautomati-
callytemperaturecorrected(ATC)moisturevalue.Ifyouneedtoread
thecurrenttemperatureofthetimberpressthe button,thentheLCD
willdisplaythetemperature.Pressthe buttonagainandtheLCDwill
displaytheother°Cor°Ftemperature.Pressthe buttonandtheLCD
willdisplaythemoisturevalueagain.
Auto Power-Off Set-up
Tochangethedefaultautopower-offtimespressthe and buttons
together.Holdthe buttonandpressthe buttontochangetheauto
power-offtime(toeitherdisabletheautopower-offortosetitfrom1to9
minutes)bychangingthecode.
0disablestheautopower-offfunction,1setstheinstrumenttoauto
power-offinoneminute,2setsittotwominutes,3tothreeminutes,and
respectfullyupto9fornineminutesfortheinstrumenttoautopower-off.
Calibration Check
Therearetwocheckedcalibratorsinthecapofthisinstrument.When
checkingthecalibration,theAscaleshouldbeselectedandthetempera-
tureprobemustbedisconnected.Usetheneedletotouchthetwopoles
ofcalibrator.Ifcorrectlycalibrated,theinstrumentwillregister%H
2
O
valuesintherange17.7to18.3(atthe“T”calibration)andintherange
25.5to26.5(at“B”calibration).Iftherangeisover+/-1theInstrument
can’taccuratelymeasurethemoistureoftimber.Openthebackcoverand
adjusttherheostattomakethetolerancemeettherange.
Care and Maintenance
Whentheinstrumentisnotinuse,keepitinitspouchtogetherwithits
accessories.Storethekitinastable,dust-freeenvironmentoutofdirect
sunlight.Removethebatteriesfromtheinstrumentifitistobestoredfor
periodsofmorethanonemonth,orwhenthebatterysymbolappearson
thedisplay.Besuretochecktheconditionoftheaccessoriesusedwith
thisinstrumentonaregularbasisandreplacethemiftheybecomeworn
or damaged.
