6. Dimensions and Technical Data
6.1 Product Specifications
6.1.1 Pump Dimensions
Model
Dimensions(mm)
A1
A2
A3
A4
B1
B2
B3
H1
H2
L1
L2
L3
L4
L5
L6
VSRM38-72
G1
G1
G3/8
11
189
158
125
75
428
336
149
131
50
96
136
VSRM48-72
G1
G1
G3/8
11
189
158
125
75
428
383
167
143
68
96
136
VSRM39-102
G1
G1¼
G3/8
11
189
158
125
75
428
362
149
125
50
96
155
VSRM58-102
G1
G1¼
G3/8
11
189
158
140
90
443
446
243
228
104
125
155
VSRM50-270
G1½
G1½
G3/8
11
210
158
125
100
550
438
200
185
80
96
136
6.1.2 Technical Data - AC 240V/50Hz Input
Model
Rated
power
Max
Head
Max
flow
Rated
head
Rated
Flow
Factory
pressure
setting
Operating
pressure
range
Pressure
tank size
Pressure filled
in tank
(KW)
(m)
(Lpm)
(m)
(Lpm)
(bar)
(bar)
(bar)
VSRM38-72
0.55
37
72
33
33
2.0
1.0~3.2
2L
2.0
VSRM48-72
0.55
47
72
40
38
2.0
1.0~4.0
2L
2.0
VSRM39-102
0.75
39
130
30
66
2.0
1.0~3.0
2L
2.0
VSRM58-102
1.3
58
130
49
66
2.0
1.0~4.9
2L
2.0
VSRM50-270
2.2
50
270
39.5
200
2.0
1.0~4.0
4L
2.0
