f) Oil Air Filter
 Checkwhethertheairlterusedisrmlyattachedtothecarburettorandsufcientlyoiledbeforeeveryrun.
Onlyawell-oiledairltercanpreventnestdustparticlesfromgettingintothemotorandcausingmotor
damage.
 Cleantheairlterregularly(washoutinpetrol)orreplaceitwithanewairlterintime.Theairlter(likethe
tyres) is a wear part.
 Iftheairlterisnotoiledsufciently,nedustparticleswillpassthroughtheairlter‘sfoam.Theseparticles
actlikeneabrasivepaperinthemotor.Afteronlyashorttime,themotorwilllosecompression.Thiscauses
loss of performance, and eventually the motor cannot be started anymore.
A motor damaged by this is not subject to guarantee/warranty!
Remove the metal lid (1) by turning out the holding screw (2).
Thenpulloutthefoamairlter.
Oiltheairlterslightlyin ordertolteroutdustparticles.Use
specialairlteroilforthis(notincludedinthedelivery,canbe
ordered separately).
Puttheairlterandsomeairlteroilintoaplasticbag.Then
compresstheairlterseveraltimessothatittakesuptheoiland
itspreadsintheairlter.
Putontheairlterandthemetallidagain,screwonthemetallid
withthescrewremovedatrst.
g) Fuelling the Vehicle
Openthetanklid(1)andllthetankwithatwo-strokemixture
(mixing ratio 1:25).
Use only high-quality fully synthetic two-stroke oil and Super fuel
(or Super Plus) for the mixture.
Close the tank again.
Two-stroke mixture with „E10“ fuel or a mixture with a lower oil share must not be used. Motor damage
threatens at non-observance; loss of guarantee/warranty!
Also read the safety notes in chapter 6. b).
Figure 5
