Reer ARGOLUX AS Series User Manual

TECHNICAL FEATURES
Emitter and receiver with a ø35mm resolution.
Emitter and receiver with a ø35mm resolution.Emitter and receiver with a ø35mm resolution.
Emitter and receiver with a ø35mm resolution.
Emitter and receiver with a ø55mm resolution.
Emitter and receiver with a ø55mm resolution.Emitter and receiver with a ø55mm resolution.
Emitter and receiver with a ø55mm resolution.
Model
ModelModel
Model AS
ASAS
AS 203
203203
203 403
403403
403 603
603603
603 703
703703
703 903
903903
903 1103
11031103
1103 1203
12031203
1203 1403
14031403
1403 1603
16031603
1603
Protection heights mm 230 400 570 745 915 1090 1260 1435 1605
Number of beams 9 17 25 33 41 49 57 65 73
Resolution mm 35
Lens pitch mm 21,5
Lens diameter mm 12
Scanning range m
0
÷
12
Ambient light immunity lx > 50.000
Response time ms 13 14 15 16 17
Power supply V
dc
24
±
20%
Power consump-
tion
at 24V
dc
Emitter
W
4,2
Receiver 3,3 4,6 6 7,4 8,8 10,1 11,5 12,9 14,3
Operating temperature °C
0
÷
55 (without condensation and ice)
Sealing IP 65
Width
mm
50
Dimensions Depth 70
Height 360 530 705 875 1050 1220 1395 1565 1735
Model
ModelModel
Model AS
ASAS
AS 405
405405
405 605
605605
605 705
705705
705 905
905905
905 1105
11051105
1105 1205
12051205
1205 1405
14051405
1405 1605
16051605
1605
Protection heights mm 440 610 785 955 1130 1300 1475 1645
Number of beams 9 13 17 21 25 29 33 37
Resolution mm 55
Lens pitch mm 43
Lens diameter mm 12
Scanning range m
0
÷
12
Ambient light immunity lx > 50.000
Response time ms 13 14 15
Power supply V
dc
24
±
20%
Power consump-
tion
at 24V
dc
Emitter
W
4,2
Receiver 3,3 4 4,6 5,3 6 6,7 7,4 8,3
Operating temperature °C
0
÷
55 (without condensation and ice)
Sealing IP 65
Width
mm
50
Dimensions Depth 70
Height 530 705 875 1050 1220 1395 1565 1735
10
1010
10
