— English Reflex ex separator — 21.11.2016
Sludge separator with removable floor flange
The separator element at the equipment can be cleaned and replaced, if required.
– The equipment must have cooled down, been emptied, and de-pressurised.
– Keep a suitable flange gasket at hand.
For cleaning, proceed as follows:
1. Use appropriate lifting gear to carefully lower the separator element and the bottom cover to the floor.
– Ensure that the separator element can neither topple nor roll away or execute other unintended movements.
– Avoid damage to the draw-off tap.
2. Remove any deposits from the separator element.
– Use a water jet or low-pressure cleaner.
Reassemble in reverse order.
3. Insert a functioning gasket and grease this with a suitable sealant.
4. Tighten the flange screws with a suitable torque.
– Tighten diagonally and step-by-step as per the state of the art.
Sludge separator with magnet insert
CAUTION
Restriction during operation in respect of medical devices due to magnetic field
The device contains permanent magnets generating a static magnetic field. Magnets may affect the functioning of cardiac pacemakers
and implanted defibrillators.
• Persons with such medical devices or other metallic implants must maintain a sufficient safe distance relative to magnets.
• Provide warning information before people enter the sphere of influence of magnets.
The device can be emptied without the operation being shut down.
For emptying, proceed as follows:
. Unscrew the magnet from the immersion sleeve.
. Provide a vessel to capture the drained material.
. Slowly or for a short time only open the draw-off tap.
. Screw the magnet into the immersion sleeve.
If no magnetic insert is fitted, steps 1 and 4 are not
needed.
