Place tool into
position
Stop and wait
for the Survey
Measure next
survey
(There is also an
opportunity to
change depth,
interval, mode and
direction)
IIIII__II
When completed
7
© Imdex Limited November 2018
104121 RTI-MAN-0170 V1
REFLEX GYRO
| SURVEY
SPRINT-IQ™

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Reflex GYRO SPRINT-IQ and is the answer not in the manual?

Reflex GYRO SPRINT-IQ Specifications

Operating Environment IconOperating Environment
operational temperature0 C to 70 C
depth3000 m
shock500 g
Battery IconBattery
battery typeNi-MH Rechargeable batteries
operating time15 hours
field changeableYes, 2 batteries supplied per kit
Weight and Dimensions IconWeight and Dimensions
outer diameter42.5 mm
length1400 mm
weight8 kg
