Measure next structure

Lift the REFLEXIQ-LOGGER™ device to align the laser with the structure, click the front button on the

top of the device to record the measurement.

If the structure is a linear feature, first measure the

angle of the plane it lies on, then measure the linear

structure by aligning the laser with the line on the

plane surface.

Press the front button on the top of the device twice (quickly) to set the QAFlag for

that reading.

Take measurements for all structures of interest

Repeat steps 5 to 7 to take measurements for all structures of interest.

to upload to Hub

Turn off device

Press and hold both side buttons until the

green and blue lights extinguish. The

REFLEXIQ-LOGGER™is now turned

off.
