Rega Planet CD Player User Manual

Loading a disc
1. Use the finger lift to open the lid.
2. Holding the disc at opposite sides, place onto the hub in
the CD tray.
3. Close the lid - the puck will clamp the disc onto the hub. If
the player is on, the disc will be read. If the player is off,
the disc will be read on power up.
4. To remove the disc: Press STOP if in play mode. When the
disc has stopped playing, lift the lid and remove the disc.
Play/Pause
Press the PLAY button with a disc loaded and the disc will start
playing from track 1.
The display will show the play symbol, track number, index number,
and the playing time.
Pressing again toggles between play and pause*. In pause mode the
pause symbol will be displayed.
*Optional Remote Control has separate play and pause buttons.
Stop
Press the STOP button to stop playing the disc. The display will
return to track 0.
1234
678
5
910
TRACK INDEX SECMINDISC
000000000.000
11 1312
14 15
1816
17
20
19
SHUFFLE PROGRAM REPEAT 1
STEP
Play
Symbol
Pause
Symbol
Shuffle
Mode
Program
Mode
Repeat
Mode
Track
Number
Index
TimeStep Music Calendar
7 8
19
888888888.888
Planet manual.qxd 28/05/2002 10:26 Page 10

Rega Planet CD Player Specifications

Laser Specifications

laser wavelength	780 nm
line output maximum level	2 V (load impedance minimum 10kΩ)
digital output maximum level	0.5 V (load impedance 75Ω)
digital sampling frequency	44.1 kHz

Power

mains voltage	230 V (minimum 190V maximum 250V)
alternative mains voltage	115 V (minimum 95V maximum 125V)
power consumption	10 W

Weight and Dimensions

dimensions	435W x 100H x 270D
required space for operation	435W x 180H x 315D
