Engine & Controls
1-59
Typical Control Lever In Neutral Position
1) Neutral Release Button 3) Control Lever
2) Trim Control Switch 4) Interrupter Switch
Typical Control Lever Showing Five Positions
Pushing the throttle control lever forward from the neutral 12
o’clock position to the 11 o’clock position will engage forward gear
with minimal throttle. From the 11 o’clock position to the 9 o’clock
position, the vessel is in forward gear with di ering levels of throttle
selections.
Pulling the throttle control lever back from the neutral 12 o’clock
position to the 1 o’clock position will engage the reverse gear
with minimal throttle. From the 1 o’clock position to the 3 o’clock
position, the vessel is in reverse gear with di ering levels of throttle
selections.
1
2
3
4
