4-11
e battery switch is located in the starboard a sump. With the
stereo performance package option normally a 40 amp breaker
protects the circuit and a 50 amp breaker protects the wiring up to
the helm.
e stereo memory and the bilge pump fuses are located near the
battery switch box as reference below. e stereo memory fuse is 15
amps and the bilge pump fuse is 5 amps. ese circuits will continue
to function even with the battery switch in the “OFF” position. It is
recommended to turn the red battery switch to the “OFF” position
when leaving the vessel for extended periods
Typical Single Battery Switch
Breakers
Stereo Memory &
Bilge Pump Fuse
Battery Switch
