4-15
DIAGRAM AND INSTALLATION INSTRUCTIONS FOR BIMINI
TOP/SUNSHADE-VESSELS WITH OPTIONAL POWERTOWER.
1. Find jaw between pins on bottom of port forward bow. Move
sliding jaw over the top pin to release the forward bow and pull up
to upper set of pins allowing the jaws to slide over the bottom pin
and locking in between the pins (yellow arrow). See gure B. Do the
same with the starboard forward bow.
2. Find one of the straight eyed arms as shown in Figure B on the
following pages. Turn the white cha ng block in a direction so its
at surface is between the straight arm and the PowerTower to
protect it. While pushing down on the starboard forward bow align
the straight arm with the forward end of the jaw and install the ball
end of the straight arm into the front of the jaw. Install a lanyard pin
which will lock it in place. Do the same with the other straight arm.
3. Locate the 90 degree a arms. ere are 2 each for the a bows. See
Figure B. Start with either side. Pull down on the a top and insert
the top arm into the top jaw. Lock the arm in place by inserting a
lanyard pin. Repeat the same process with the lower 90 degree arm.
Follow the same procedure with the 90 degree arms on the other
side.
4. Note that the forward bow utilizes a strap and latch similar to
the latch on the boot. is strap assists in holding the bimini top
down as the vessel is making forward headway. Attach the upper
and lower strap together and attach at the camel-back.
Remember not to exceed 35 mph with the bimini top up on the
waterways Also, the bimini top must be disassembled and zipped
into the boot before towing on the highway.
