REFERENCE ONLY
NOTES:
1) Dimensions given are for reference,
use splashes/fixtures to locate hardware.
STERN EYE
BRONZE DRAIN PLUG
7
1
2
5
FUEL VENT
BOW SCUFF PLATE SS
1
3
DRAIN
ELECTRIC HORN
1
6
QTY.
1
1
DESCRIPTION
DOCKING LIGHTS (Optional)
1
BILL OF MATERIALS
8
ITEM
14
1
CHROME PLATE NYLON THRU HULL
2
DRAWN BY:
PROPRIETARY AND CONFIDENTIAL:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE
INDUSTRIES. ANY REPRODUCTION IN PART OR AS WHOLE WITHOUT THE WRITTEN
PERMISSION OF REGAL MARINE INDUSTRIES IS PROHIBITED.
REVISION:
ALL RIGHTS RESERVED
DWG. NO.:
REGAL MARINE INDUSTRIES
PAGE:
DATE:
2300 JETPORT DRIVE
ORLANDO, FLO RIDA 32809
TEL (407) 851-4360
-
2000 (FP) Hull Hardware
1 OF 1
02/25/14
APPROVED BY:
MFP24BJAH
Mike B.
DRAWING TITL E:
TRANSOM VIEW
STARBOARD VIEW
(27")
(52")
(15 1/4")
(15 1/4")
Ø7/8"
Ø1 3/8"
(12 1/4")
(2")
Ø1 1/8" (Centered)
(12")
