4-12
OTE: N The VSR uses a LED type light that indicates that the
VSR is closed and is sending a charging current to the
batteries.
If the LED light stays on after the engine is turned off do
not panic. This is a normal condition. The residual battery
voltage because of battery charging has not yet dropped
below 12.8 volts for the VSR to cut out.
Breaker Panels
Your vessel features 2 main breaker panels. One of these panels is
located at the helm area. Become familiar with the components that this
panel protects. Should a breaker “trip” nd the cause of the problem
before resetting the breaker. Push in on the breaker to reset it.
Select breakers may not be used on your boat for optional accessories.
UNDER HELM BREAKER PANEL
