Cosmetic Care & Maintenance
7-17
Fuel Tank & Fittings
WARNING
Be sure to inspect the entire fuel system for deterioration and
leakage at least once a year. Failure to inspect the entire fuel
system at least once a year may result in fire and explosion
caused by a deteriorated and/or leaking fuel system component
that could result in death and serious injury.
Periodically inspect the fuel tank components for loose clamps at the
vent including charcoal canister, ll and feed locations. Examine each
hose for signs of deterioration and leakage. Check the fuel sender for
loose bolts, nuts, and leaks at all areas of contact. Also, inspect the
fuel tank for signs of leakage or abrasion. Tighten all components as
needed. Inspect entire fuel system at least once per year.
FUEL FEEDS
FUEL SENDER
ANTI-SIPHON VALVE
TYPICAL EPA COMPLIANT FUEL TANK
FUEL VENT
FUEL FILL
CARBON CANISTER
INTERNAL VALVE
