Regal 3300 - Page 284

11-20
A
LABELLABEL
DRAWN BY:
C.W.
Detail "A"
Gas Fuel System
MNC23F
9-21-12
Fuel Tank
12-17-12
REVISION DESCRIPTION
SHEET:
PROPRIETARY AND CONFIDENTIAL
Fuel Tank
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION
IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF
REGAL MARINE INDUSTRIES IS PROHIBITED
DWG. NO.:
REGAL MARINE INDUSTRIES
REV. DATE
APPROVED BY:
2300 JETPORT DRIVE
ORLANDO, FLORIDA 32809 TEL (407) 851-4360
CW
SCALE:
APP. BY
1-1
11-26-12
50%
Waste Tank
Water Tank
MJ
Changed Water/Waste Tank Location
DR. BY
CW
DC
DATE:
Starboard Side Interior View
Changed Starboard Fuel Line Routing
PB
ALL RIGHTS RESERVED
DRAWING TITLE:
Fuel Tank Sending Unit
Fuel Vent
Fuel Fill Located On Deck
Charcoal Filter
3/8" x 2" x Length Of Fuel Tank Plastic Foam Tape Typical
3/8" x 2" x 11" PlasticFoam Tape At Brackets
3/8" x 2" x 11
"
Plastic Foam
Tape At Brackets
Starboard Engine
Fuel Supply
Port Engine
Fuel Supply
3300 Bow Rider Typical EPA-Compliant Fuel Tank Installation
