Gate Assembly
STEP 3
Place the main gate panel with the hinge adjuster knobs into the upper and
lower hinges on the wall. Press the main gate panel in a downward motion to
set the hinge adjuster knobs into the hinges.
STEP 4
Place the second gate panel with the receiver adjustment knob in front of the
hanging main gate panel. Slide the main gate panel to the left so that the
receiver adjustment knobs are approximately 1/4" from the wall. When the
panels are correctly aligned there will be no space between the vertical bars
on each panel.
(SHOWING MAIN GATE PANEL SET IN THE HINGE)
(CORRECT ALIGNMENT)
(INCORRECT ALIGNMENT)
