Before Assembly
PLEASE CHECK TO MAKE SURE YOU HAVE THE FOLLOWING PARTS:
Main Gate Panel (2)
Wall Mount Hinge, Snap, Male (1)
Wall Mount Hinge, Snap, Female (1)
Upper Assembly, Mount Wall, Latch (A) (1)
Lower, Mount, Wall, Hinge (1)
Lower, Mount, Wall Latch (A) (1)
Hinge Adjuster Knob (2)
Receiver Adjustment Knob (2)
G
J
F
A
H
K
I
B
C
D
E
2" Wood Screw (8)
Coupler, Male (2)
Coupler, Female (2)
Handle Mounting Paper (1)
Hinge Mounting Paper (1)
Upper Assembly, Mount Wall,
Latch (B) (1)
A
B
C
D
E
F
G
H
I
J
K
L
M
L M
N O
N
O
Lower, Mount, Wall Latch (B) (1)
