Regency Ei29 - Page 28

28
Installer's Information
Fill Outer grate with ginger crystals.
1
Place 3x log B as shown.
3
Place 4x log A as shown.
Ensure that the logs go under the grate post as shown below to
allow room for the 3 logs to be installed in next step.
2
Fill gaps in the inner grate with ginger crystals.
4
Place 2x log C on top of crystals on either side of outer grate.
5
OAK LOG LAYOUT
A B C D
x5 x7 x3 x4
E F G
x1 x1 x3
Ginger
Crystals
Black
Crystals
