Installer's Information
Hearth Trim Installation - Mounting Hearth Trim
1a. For Gi29 installs, loosely attach the hearth trim using the included
screws from the top down.
2a. Without premium surround: slide the hearth trim as far forward as
possible (careful not to scratch it) and tighten the screws.
2b. With premium surround: slide the hearth trim as far back as
possible (careful not to scratch it) and tighten the screws.
1b. For Ei29 installs, loosely attach the hearth trim using the included
screws from the bottom up.
2
Hearth Trim Installation (Part # 311-941 )
