Regency U41 - Main Assembly; Parts List

19
Regency U41-3 ULTIMATE Gas Fireplace Insert
PARTS LIST
MAIN ASSEMBLY
Part # Description Part # Description
27) 910-142 Thermodisc - Fan Auto/On/Off
28) * Thermodisc Bracket
30) 610-175 Rear Panel
31) 591-187 Firebox Baffle Plate
908-727 Manual
*Not available as a replacement part.
1) 611-525 Bottom Louver Assy
2) 653-535/02 Top Louver Assy
9) 590-105 Fan Cover
10) 936-196 Fan Cover Gasket
610-517/P Fan Assembly (120 V)
11) 910-157/P Fan Motor
12) 910-794 Power Cord (120 V)
910-770 Wire Harness (stove connection end)
19) 613-520 Side Panel Assy - Left
20) 650-527 Side Panel Hinge Bracket - Left
21) 613-522 Side Panel Assy - Right
22) 650-528 Side Panel Hinge Bracket - Right
23) 710-028 Faceplate Mounting Bracket
24) 948-241 Door Latch
25) 910-325 Spill Switch
26) 610-576 False Top Assembly
836-220 False Top Insulation
