Regency Ultimate U39E Series - Conversion from NG to LP

Regency
®
U39E-11 ULTIMATE™ Freestanding Gas Stove | 31
installation
Conversion from NG to LP
THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER
IF IN DOUBT DO NOT DO THIS CONVERSION !!
920-050
01.30.19
1
U39
Conversion from NG to LPG
THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER
IF IN DOUBT DO NOT DO THIS CONVERSION !!
1. Shuto󰀨thegasandelectricalsupply.
2. Removethesafetyscreen,openthe
frontdoorandcarefullyremovethelogs
andlavarock.
Pilot assembly is now accessible .
Each Kit contains one LPG
Conversion Kit #733-977
LPG Conversion Kit Contains:
Qty. Part # Description
1 904-529 5/32"AllenKey
1 904-645 BurnerOrice#51
1 918-590 Label"Convertedto
LPG"
1 908-528 Red"LPG"label
1 910-037 LPGInjector
 (PilotOrice)
1 911-011 Steppermotor
1 920-050 InstructionSheet
Note: Use a magnetic type screwdriver
if possible.
4. Openpedestaldoorandremovethe
chainfromdoorwhichwillallowdoorto
fall.
3. Removeburner.Seediagrambelow.
7. Turncontrolknobtothe“OFF”position.
8. RemoveNGsteppermotorbyremoving2
screwsinlocationsshownbelow–replace
withLPsteppermotor,secureinplace
with2screws.
9. Pullo󰀨thepilotcaptoexposethepilot
orice.
10.Unscrewthepilotoricewiththeallen
keyandreplacewiththeLPGpilot
oriceinthekit.
11.ReinstallnewburneroriceLPG
stamped#50andtighten.
13.Checkforgasleakswithapropersoapy
solutionorleakdetector.
14.Checkforpropersparkbetweenthe
ignitorandpilotcap.Referto"Lighting
Procedure"sectionofthemanualfor
lightingsequence.
15.Checkpilotames.Correctamepat-
ternhas3strongblueames.Adjust-
mentcanbemadebyturningtheslotted
screwatthetoprightcornerofthe
valve.Referto"MaintenanceInstruc-
tions"sectionofthemanualforcorrect
amepatterns.
16. ReverseSteps9-1.
17.Attachthelabel"Thisunithasbeen
convertedtoLPG"nearorontopofthe
Serial#decal.
18.Replaceyellow"NG"labelwithred
"LPG"label.
19.Checkoperationofamecontrol.
20.Theburneraerationshouldbesetto
1/2"openforL P.
 Seeaerationadjustmentdetailsinthe
manual.
21.Checkforproperameappearanceand
glowonlogs.
Burner Orice
12.Removeburneroricewitha1/2"
wrenchwhileusinga9/16"wrenchto
holdontotheelbowbehindtheorice,
thendiscardtheorice.
Installer Notice:
These instructions must be left
with the appliance.
6.Removefourscrewstoremovetheac-
cesspanel(inlocationsshownbelow)
andthechainattachedtothefrontdoor
andtheunit.
Remove chain
here
5.Remove2screwsthatsecurethefront
doortotheunit.Onescrewisontheleft
handsideandtheotherontherighthand
side.(Leftsideshown).
