EDGE
TM
PE-Xa
installation pipes
Size Horizontal Installation Vertical Installation
Concealed Exposed REHAU
support
channel
Concealed Exposed REHAU
support
channel
Max. recommended spacing of brackets
and clips (m)
Max. recommended spacing of brackets
and clips (m)
16 0.60 0.30 2.0 1.20 1.20 2.0
20 0.70 0.40 2.0 1.40 1.40 2.0
25 0.75 0.50 2.0 1.50 1.50 2.0
32 0.85 0.70 2.0 1.70 1.50 2.0
EDGE Silver
EDGE Green
EDGE Red
EDGE Lilac
T
ab. 6-3 Recommended spacings of pipe bracket/clip for EDGE
TM
PE-Xa pipes
