7.4 “CAM1-GUIDE” function:
This function allows a better visualization of the obstacle’s distance behind the
vehicle. This function inserts lines in the image helping the driver during maneuver the
car.
7.5 “SW TIMER” function:
Switch the images between “VIDEO 02” and “VIDEO 03” inputs. The switching
images speed between the inputs is configurable by the user.
Predefined values are “OFF” to “08”.
7.6 “MIRROR” function:
This function sets the image in “mirror view” mode. This mode allows the obstacles
that are located at the right vehicle side appear to the left monitor side. The camera
can be installed to get a front view and/or rear view. This function makes that the
image is always compatible with both sides where the obstacles are located.
7.7 “PICTURE” function:
Allows changing the picture adjustments:
- CONTRAST
- BRIGHTNESS
- TINT
- COLOR
- SHARPNESS
- COLOR TINE
- SCALE
7.8 OSD function:
Allows changing the OSD menu settings:
- DURATION: Adjust the duration time of the OSD menu.
- HALFTONE: Adjust the transparency of the OSD menu.
- INFORMATION: Used to verify the image information.
- MEMORY RECALL: Used to set the default factory values
