REI 7" - Monitor Operations

9
6 – TECHNICAL SPECIFICATIONS:
6.1 – 7” TFT LCD Monitor
Item
Min.
Typ.
Max.
Unit
Rated Power Source
9
24
32
Vdc
Durable Temperature Range
-20
−
80
°C
Pixels
480 x 234
Pixel
Color System
NTSC / PAL
−
Power Consumption
3 ~ 12
W
Input Impedance
75
Ω
Output Level Video
1
Vp-p
Dimensions (closed) (W x H x D)
110 x 184 x 12
mm
Weight
0,400
Kg
7 – OPERATIONS:
7.1 Video Input:
VIDEO 01: Special input for a rear-view camera. This input allows the “CAM-GUIDE”
function which modifies the image inserting four approaching levels, also allows the
“TRIGGER” function.
VIDEO 02: Camera input.
VIDEO 03: Camera input.
7.2 Trigger function:
Receives the trigger signal (24Vdc) when the car is put into reverse. When the
system is in Standby mode and the TRIGGER function is activated, the screen is ON
automatically showing the image sent to the input “VIDEO 01”. In case the screen is
already ON, the input “VIDEO 01” is also enabled automatically.
7.3 12Vdc Output:
This is a power output supply for the system cameras avoiding the use of a 24Vdc /
12Vdc external converter.
