Rekluse Core EXP - Included Parts

Rekluse Core EXP - Hydraulic Page 3
INCLUDED PARTS
Item
Item Type
Qty
5
Pressure Plate
1
13
EXP Base *
2
16
Steel Lining Plate
1
23
Clutch Cover
1
27
Center Clutch Hub
1
31
Screw Sleeve
6
47
Fastener – M6 Pressure Plate Bolt
6
51
Fastener - 1/4-Turn Pin *
6
54
Orange Free Play Gain Rubber Band
1
60
Pressure Plate Spring
6
60.X
EXP Adjustment Spring * (extra springs are included, see last page for EXP tuning options)
6
63
Steel Drive Plate (TEC Plate)
9
85
Wedge Assembly *
6
86
Adjustable Slave Cylinder Assembly (bleed syringe included)
1
88
Pressure Plate Bolt &Spring Assembly
1
* Denotes parts assembled as part of EXP disk assembly
Visit Rekluse.com/support for a full parts fiche illustration and part numbers.
