Section V Tightening torques
Front Suspension
Lower ball joint (pin) 7/16" UNF 4.29-4.98kg/m 31-36 lb/ft
Spring/damper unit top fixing 3/8" UNF 4.15-4.84 kg/m 30-35 lb/ft
Spring/damper unit lower fixing 1/2" UNF 4.84-5.53 kg/m 35-40 lb/ft
Upper ball joint (pin) 7/16" UNF 4.98-5.67 kg/m 36-41 lb/ft
Upper wishbone to pivot bracket 3/8" UNF 4.15-4.84 kg/m 30-35 lb/ft
Upper wishbone pivot to chassis 3/8" UNF 4.15-4.84 kg/m 30-35 lb/ft
Lower wishbone to ball joint 5/16" UNF
Lower wishbone to chassis 7/16" UNF 5.53-6.22 kg/m 40-45 lb/ft
Front strut to chassis 7/16" UNF 5.53-6.22 kg/m 40-45 lb/ft
Front strut to lower wishbone 5/16" UNF 2.07-2.49 kg/m 15-18 lb/ft
Anti-roll bar link to wishbone 7/16" UNF 4.15-4.84 kg/m 30-35 lb/ft
Anti roll bar to link 7/16" UNF 4.15-4.84 kg/m 30-35 lb/ft
Anti roll bar clip to chassis 1/4" UNF 1.11-1.38 kg/m 8-10 lb/ft
Rear suspension
Damper to frame 3/8" UNF 4.15-4.84 kg/m 30-35 lb/ft
Damper to axle 3/8" UNF 4.15-4.84 kg/m 30-35 lb/ft
"U" bolt to spring M10 4.15-4.84 kg/m 30-35 lb/ft
Shackle to chassis 1/2" UNF 4.84-5.53 kg/m 35-40 lb/ft
Leaf spring to shackle 1/2" UNF 4.84-5.53 kg/m 35-40 lb/ft
Leaf spring to chassis 1/2" UNF 4.84-5.53 kg/m 35-40 lb/ft
Steering
Steering wheel to column 9/16" UNF 2.76-3.46 kg/m 20-25 lb/ft
Steering rack to chassis 5/16" UNF 2.07-2.49 kg/m 15-18 lb/ft
Steering column universal joint pinch bolts 5/16" UNF 2.76-3.18 kg/m 20-23 lb/ft
Steering rack damper preload cover bolts M6 0.83-1.11 kg/m 6-8 lb/ft
Track rod ends (pins) 3/8" UNF 3.59-3.87 kg/m 26-28 lb/ft
Cooling system
Water pump fixing nuts 5/16" UNF 1.66-2.10 kg/m 12-15 lb/ft
Engine
Cylinder head nuts 3/8" UNF 3.46 kg/m 25 lb/ft
5/16" UNF 2.07 kg/m 15 lb/ft
Big end bearing caps 5/16" UNF 2.90 kg/m 21 lb/ft
Main bearing caps 3/8" UNF 3.32 kg/m 24 lb/ft
Flywheel to crankshaft bolts 3/8" UNF 4.04 kg/m 29 lb/ft
Rocker shaft nuts 3/8" UNF 3.04 kg/m 22 lb/ft
Manifold nuts 5/16" UNF 2.07 kg/m 15 lb/ft
Fuel pump nuts 5/16" UNF 2.07 kg/m 15 lb/ft
Rocker cover nuts 5/16" UNF 0.3 kg/m 2 lb/ft
Spark plugs M14 2.07 kg/m 15 lb/ft
Engine mountings 3/8" UNF 3.46 kg/m 25 lb/ft
Gearbox
Gearbox to engine (nuts) 5/16" UNF 1.66-2.07 kg/m 12-15 lb/ft
Gearbox to engine (bolts) 5/16" UNC 2.07-2.49 kg/m 15-18 lb/ft
Front cover 1/4" UNF 0.69-1.10 kg/m 5-8 lb/ft
Rear cover 1/4" UNC 0.83-1.24 kg/m 6-9 lb/ft
Top cover 1/4" UNC 0.83-1.24 kg/m 6-9 lb/ft
Drain and filler plugs 3/4" gas thread 2.07-2.76 kg/m 15-20 lb/t
Gearbox mounting to support frame 3/8" UNF 2.76-3.46 kg/m 20-25 lb/ft
Support frame to chassis 5/16" UNF 2.07-2.49 kg/m 15-18 lb/ft
Main shaft to flange nut 1/2" UNF 6.92 kg/m 50 lb/ft
Clutch
Clutch cover to flywheel 5/16" UNF 1.66-2.07 kg/m 12-15 lb/ft
