Page 34
Section F
Contents
Description
Routine maintenance
Engine service operations, engine removal, hoist bracket
Operation 1 Engine removal
Operation 2 Flywheel and ring gear removal and
replacement
Operation 3 Sump removal and replacement
Operation 4 Oil pump removal (sump removed)
Operation 5 Crankshaft rear cover and oil seal replacement
(with sump removed)
Operation 6 Timing chain cover, oil seal and gasket
replacement (without engine removed)
Operation 7 Timing chain replacement (with front cover
removed)
Operation 8 Camshaft sprocket alignment (timing chain
cover and timing chain removed)
Operation 9 Cylinder head removal (without engine
removal)
Operation 10 Cylinder head decarbonise (with cylinder head
removed)
Operation 11 Pistons, connecting rods and bearings
replacement (with cylinder head and sump
removed
