Reloop MIXON 4 Description

NO NAME FUNCTION +SHIFT FUNCTION
21 Pitch Fader Adjusts the Pitch of the loaded Track/Remix Set
22 SLIP Button Activates/deactivates SLIP Mode VINYL: Activates/deactivates Vinyl Mode
23 Key LOCK Button Activates/deactivates Key LOCK PITCH RNG.: Selects the Pitch Range (in %)
24 Key SYNC Button
Press Key SYNC & PARAM -/+ to change the Key of the loaded
Track, double click on Key SYNC resets the Key
CENSOR: Sets a Loop and enables SLIP Mode
25 LOOP Encoder
Adjusts the length of the Loop, turn left for decrease,
turn right for increase
LOOP MOVE: Shifts the Loop by the given MOVE value
26 AUTO LOOP Button Sets a Loop
27 PARAM – Button BeatJump backwards Decreases the MOVE value
28 PARAM + Button BeatJump forwards Increases the MOVE value
29 SYNC Button Activates/deactivates SYNC
30 CUE Button Sets a momentary Cue Point CUP: The loaded Track starts automatically from this Cue Point
31 PLAY/PAUSE Button Starts/Stops the loaded Track/Remix Set
32 JOGWHEEL
VINYL Mode ON: Acts like a Platter on a Turntable
VINYL Mode OFF: Adjusts only the Phase of the loaded Track/
Remix Set
SEARCH: Scroll through your Track
33 SHIFT Button
By pressing this Button various functions
become accessible (Hold)
34 DECK Button Switches between Deck 1/3 and 2/4
DECK CONTROL
EFFECT SECTION
35
39
36
40
37
41
38
42
21
22
23
24
25
26
27
29
30
31
28 33 34
32
NO NAME FUNCTION +SHIFT FUNCTION
35 PARAM1 Knob Adjusts the value of Paramter 1 Scroll through the Effects for the EFFECTS1 Slot
36 PARAM2 Knob Adjusts the value of Paramter 2 Scroll through the Effects for the EFFECTS2 Slot
37 PARAM3 Knob Adjusts the value of Paramter 3 Scroll through the Effects for the EFFECTS3 Slot
38 BEATS/PARAM. Encoder Adjusts the Dry/Wet Ratio
39 EFFECT1 Button
In GROUP Mode: Activates/deactivates the loaded Effect,
In SINGLE Mode: Functionality depends on the choosen Effect
Select Effects for the EFFECTS1 Slot
40 EFFECT2 Button
In GROUP Mode: Activates/deactivates the loaded Effect,
In SINGLE Mode: Functionality depends on the choosen Effect
Select Effects for the EFFECTS2 Slot
41 EFFECT3 Button
In GROUP Mode: Activates/deactivates the loaded Effect,
In SINGLE Mode: Functionality depends on the choosen Effect
Select Effects for the EFFECTS3 Slot
42 BEATS/PARAM. Button
In GROUP Mode: Resets the Dry/Wet Ratio,
In SINGLE Mode: Activates/deactivates the choosen Effect
Switches between GROUP/SINGLE Mode

Reloop MIXON 4 Specifications

General

Product color	Black
Scratcher type	Digital Vinyl System (DVS) scratcher
Platter backlight	Yes
Number of drum pads	8
Built-in optical drive	-
Number of mixer channels	4 channels
Number of scratcher platters	2
USB ports quantity	1
Headphone connectivity	3.5 mm/6.35 mm
Microphone connectivity	6.3 mm
Current	3 A
Input voltage	12 V
Power supply type	DC
Minimum RAM	4 GB
Minimum processor	32 bit/64 bit: i3 / i5 / i7
Minimum processor speed	1.07 GHz
Minimum storage drive space	5000 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
Minimum display resolution requirement	1280 x 720 pixels
Built-in display	No
Cables included	AC, Lightning, USB

Weight and Dimensions

Depth	376 mm
Width	657 mm
Height	45 mm
Weight	5300 g
