RELOOP MIXON 4
FIRMWARE UTILITY SETTINGS
1. LED CHECK MODE
Turn on all LEDs:
Press and hold the PLAY-button while
powering on the unit
Each LED is now being illuminated. By
pressing any LED back lit button, the LED
can be turned on and off to check the re-
sponsiveness.
2. FIRMWARE VERSION CHECK
Before you update your rmware, you can check whether the rmware version is already installed on the unit before proceeding. In case
the displayed rmware version matches the downloaded rmware, no update is necessary.
Press and hold the CUE-button while powering on the unit
One lit LED of the left Master VU-Meter represents a step of 10.
One lit LED on the right VU-Meter represents a step of 1.
In the example on the left the current shown values represent 19.
One lit LED on the left drum pad section represents a step of 10.
One lit LED on the right drum pad section represents a step of 1.
In the example on the left the current shown values represent 13.
The current installed rmware is v1913.
Revision v2 (11/16)
PLEASE REGULARLY CHECK FOR
UPDATES ON WWW.RELOOP.COM

Reloop MIXON 4 Specifications

General

Product color	Black
Scratcher type	Digital Vinyl System (DVS) scratcher
Platter backlight	Yes
Number of drum pads	8
Built-in optical drive	-
Number of mixer channels	4 channels
Number of scratcher platters	2
USB ports quantity	1
Headphone connectivity	3.5 mm/6.35 mm
Microphone connectivity	6.3 mm
Current	3 A
Input voltage	12 V
Power supply type	DC
Minimum RAM	4 GB
Minimum processor	32 bit/64 bit: i3 / i5 / i7
Minimum processor speed	1.07 GHz
Minimum storage drive space	5000 MB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
Minimum display resolution requirement	1280 x 720 pixels
Built-in display	No
Cables included	AC, Lightning, USB

Weight and Dimensions

Depth	376 mm
Width	657 mm
Height	45 mm
Weight	5300 g
