Reloop TOUCH Service Manual

..2 PT11106616 Button 4
0.1 PT1110662201 Knob(Printing White) 15 3
0.1 PT1110662401 VR Cap(Printing) 1 44
0.1 PT1110662607 Button(<)(Printing) 2 23
..2 PT11106626 Button 2
0.1 PT1110662608 Button(>)(Printing) 2 22
..2 PT11106626 Button 2
0.1 PT1110662803 Button(SYNC)(L)(Printing) 1 26
..2 PT11106628 Button(CUE) 1
0.1 PT1110662804 Button(SYNC)(R)(Printing) 1 45
..2 PT11106628 Button(CUE) 1
0.1 PT1110662901 VR Cap(Printing) 2 2
0.1 PT1110663002 Button(ON)(Printing) 8 29
..2 PT11106630 Button 8
0.1 PT1110663004 Button(SHIFT)(Printing) 2 24
..2 PT11106630 Button 2
0.1 PT1110663010 Button(PAD MODE)(Printing) 2 55
..2 PT11106630 Button 2
0.1 PT1110663014 Button(MODE)(Printing) 2 25
..2 PT11106630 Button 2
0.1 PT1110663015 Button(Param)(Printing) 2 54
..2 PT11106630 Button 2
0.1 PT11106634 Lid 2 21
0.1 PT1110668201 Button(CUE)(Left)(Printing) 1 27
..2 PT11106682 Button 1
0.1 PT1110668202 Button(CUE)(Right)(Printing) 1 46
..2 PT11106682 Button 1
0.1 PT1110668203 Button(PLAY/PAUSE)(Left)(Print 1 28
..2 PT11106682 Button 1
0.1 PT1110668204 Button(PLAY/PAUSE)(Right)(Prin 1 48
..2 PT11106682 Button 1
0.1 PT1110670801 VR Cap 12 5
0.1 PT111079301 Wheel (Painting) 2 11
..2 PT1110793 Wheel 2
...3 LAC67MAR1008 Label 2
...3 MT1105596 Jog Axis 2
0.1 PT113028001 Cabinet(Printing & Painting) 1 16
..2 PT1130280 Cabinet 1
0.1 PT1130310701 Bottom Chassis(Printing & Pain 1 49
..2 PT11303107 Bottom Chassis 1
0.1 PU008008025 Conductive Foam 2 10
0.1 PU010010020 Conbuctive Foam 2 70
0.1 PW63100UC01
Ac Power Supply Cord Long 1M UL+CSA(01)
1
PW33100EU01 Ac Power Supply Cord Long 1M EU(02)
PW43100SAA02 Ac Power Supply Cord Long 1M SAA(04)
PW63100JIS01 Ac Power Supply Cord Long 1M JIS(07)
0.1 RU1104440 Heat Conductive Rubber 1 82
0.1 RU1110696 Rubber Button 2 43
0.1 RU1130737 Rubber Foot 4 60
0.1 SC0306PBBI Screw M3X6 PBB Tapping 10 47
0.1 SC0308RINI Screw M3X8 PPN 1 30
0.1 SC0310RBBI Screw M3X10 PPB Tapping 16 50
0.1 SC2608PBNI Screw M2.6*8 PPN Tapping 34 41
0.1 SC2612PBBI Screw M2.6*12,PPB TAPPING 2
0.1 SPSA036RBBN2-YH Switch Adaptor 12V/3A 1
0.1 TFTUMSH9099MD-T TFT 7.0" Diagomal UMNH9099MD-T 1 13
0.1 WR0520003503 Shieding Cable 5 pin Single Row Pitch 1 66
0.1 WR0920003003 Shielding Cable 9Pin Single Row Pitch 1 67
0.1 WRUSB05200015W2 ISOLATION CABLE USB2.0 5PIN SI 3 76
0.1 WRUSB05200020W4 Isolation Cable USB2.0 5Pin Si 1 77
0.1 WS1080310IC Washer 1 31
0.1 WS1306505 Washer FLAT 13*6.5*0.5MM 2 14
0.1 TWPC15C03801 Control PCB Assembly-B 1 12

Reloop TOUCH Specifications

General

MIDI	24 bit
Platter size	5 \
Product color	Black
Scratcher type	Digital Vinyl System (DVS) scratcher
Platter backlight	Yes
Number of drum pads	16
USB direct playback	-
Built-in optical drive	No
Number of mixer channels	2 channels
Number of scratcher platters	2
Headphone outputs	1
Power supply type	DC
Display type	LED
Display diagonal	7 \

Weight and Dimensions

Depth	377 mm
Width	594 mm
Height	43 mm
Weight	3700 g
