Reloop TOUCH Service Manual

..2 AL2-51-4401 TRANSISTOR 2N4401 NPN 2 Q1A,1B
..2 AL2-51-4403 TRANSISTOR 2N4403 PNP 2 Q700,701
..2 AL2-73-4051 IC 74HC4051 Single 8-Chan 4 IC900~903
..2 CS047C5003NPO
CCAP SMD 4.7pF/50V ±0.25pF 0603 NPO
4 C623~626
..2 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 7 C705~708,711,717,718
..2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 31
C805,806,809,810,901~908,911~918,922~9
24,926,928,930,932,935~938
..2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 56
C1A,1B,C600~606,608,610,612,616~619,62
2,627~630,632,633,635,636,639~646,650,7
00~704,710,712,715,716,800,803,804,807,9
00,910,920,921,925,927,929,931,934
..2 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 4 C609,611,613,620
..2 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 2 C607,621
..2 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 2 C614,615
..2 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 2 C631,634
..2 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO 2 C637,638
..2 CS470J5003NPO CCAP SMD 47pF/50V 5% 0603 NPO 1 C709
..2 DIEN1N4148WSM Diode SMD 2 D700,701
..2 DIPH574 Photo Sensor 2 SEN1A,1B
..2 DISDB540C-13-F Schottky Barrier Rectifier Dio 1 D600
..2 DISDBAT54CSM Zener Diode BAST54C 18 D800~817
..2 ECS10716D Capacitor Electrolytic 100uF/16V D type 14 EC601~603,605~609,612~614,616,617,700
..2 ECS22716E Ecap 220uF/16V 6.3*7.7mm SMD 4 EC600,604,611,615
..2 ECS22725FLE ECAP LOWESR 220/25V 8*10MM SMD 1 EC610
..2 FCN1T1002201 FCN Down Touch 90° Pitch=1.0mm 1 FCN600
..2 FCN1T1004001 FCN Down Touch zif smd Pitch=1.0mm 1 FCN800
..2 IC74HC138D IC 74HC138D 1 IC800
..2 IC74HCT157D IC 74HCT157D 1 IC700
..2 IC74HCT595D IC 74HCT595D 7 IC701~704,706,708,709
..2 IC74LVC1G14DBVR IC SN74LVC1G14DBVR 1 IC705
..2 IC74LVC1G17SE-7 IC 74LVC1G17SE-7 2 U1A,1B
..2 ICCY7C65642-28 IC CY7C65642-28 1 IC603
..2 ICFSUSB31K8X IC FSUSB31K8X 2 IC601,602
..2 ICNJM7805DL1A IC NJM7805DL1A 3 IC600,607,608
..2 ICYH104C08 IC YH104C08 (MCF51JF128+Program) 1 IC605
...3 ICMCF51JF128VLH IC MCF51JF128VLH 1 -
..2 ICYH104C09 IC YH104C09 (PIC12F615+Program) 1 IC606
...3 ICPIC12F615 IC PIC12F615 1 -
..2 LDJ1M1F1BB7R4S3 Liquid-emitting Diode Red/Green/Blue SMD 8 LD727~734
..2 LDKPT-1608CGCK Liquid-emitting Diode Green SMD 6 LD701,702,704,705,717,718
..2 LDKPT1608VRYX1F LED Yellow SMD 0603 120° 2 LD721,722
..2 LDLTST-C190KSKT Liquid-emitting Diode Amber SMD 10 LD700,706~709,711,715,716,723,724
..2 LDLTST-C193TBKT Liquid-emitting Diode Blue SMD 5 LD710,712~714,720
..2 LDLTST-C193TGKT Liquid-emitting Diode Green SMD 2 LD725,726
..2 LDLTW-C191TS5 Liquid-emitting Diode White SMD 2 LD703,719
..2 MT1104417901 Ground Plate(Painting) 2 (VR922)
..2 PC15C038 Control PCB-B 1 -
..2 RS000004J06 RESISTOR 0Ω 5% SMD 1206 1 R613
..2 RS000010J03 RESISTOR 0Ω 5% SMD 0603 4 R900~903
..2 RS001M10F03 RESISTOR 1M 1% SMD 0603 3 R609,633,745
..2 RS002210F03 RESISTOR 22Ω 1% SMD 0603 2 R634,649
..2 RS003310F03 RESISTOR 33Ω 1% SMD 0603 3 R629,636,637
..2 RS010010F03 RESISTOR 100Ω 1% SMD 0603 17
R618,620,623,624,632,635,737~740,746,76
9,770,904~907
..2 RS010K10F03 RESISTOR 10K 1% SMD 0603 24
R3A,R3B,R604~607,616,621,622,630,631,6
38,639,640,643~648,700,736,743,802
..2 RS015K10F03 RESISTOR 15K 1% SMD 0603 1 R642
..2 RS01K510F03 RESISTOR 1.5K 1% SMD 0603 1 R641
..2 RS022010F03 RESISTOR 220Ω 1% SMD 0603 2 R719,720
..2 RS027010F03 RESISTOR 270Ω 1% SMD 0603 4 R703,704,706,707
..2 RS02K210F03 RESISTOR 2.2K 1% SMD 0603 2 R614,615
..2 RS033010F03 RESISTOR 330Ω 1% SMD 0603 8 R754,755,758,759,761,763,764,767
..2 RS033210F03 RESISTOR 332Ω 1% SMD 0603 2 R2A,2B

Reloop TOUCH Specifications

General

MIDI	24 bit
Platter size	5 \
Product color	Black
Scratcher type	Digital Vinyl System (DVS) scratcher
Platter backlight	Yes
Number of drum pads	16
USB direct playback	-
Built-in optical drive	No
Number of mixer channels	2 channels
Number of scratcher platters	2
Headphone outputs	1
Power supply type	DC
Display type	LED
Display diagonal	7 \

Weight and Dimensions

Depth	377 mm
Width	594 mm
Height	43 mm
Weight	3700 g
