Reloop TOUCH Service Manual

..2 RS036010F03 RESISTOR 360Ω 1% SMD 0603 20 R712~717,721,722,725~735,744
..2 RS043010F03 RESISTOR 430Ω 1% SMD 0603 9 R702,705,708~711,718,723,724
..2 RS047K10F03 RESISTOR 47K 1% SMD 0603 1 R617
..2 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 4 R800,801,803,804
..2 RS056210F03 RESISTOR 562Ω 1% SMD 0603 2 R1A,1B
..2 RS05K610F03 RESISTOR 5.6K 1% SMD 0603 1 R701
..2 RS064910F03 RESISTOR 649Ω 1% SMD 0603 1 R608
..2 RS068010F03 RESISTOR 680Ω 1% SMD 0603 8 R753,756,757,760,762,765,766,768
..2 RS068K10F03 RESISTOR 68K 1% SMD 0603 1 R741
..2 RS0R0501J12 RESISTOR 0.05Ω 5% SMD 2512 4 R600~603
..2 RS100K10F03 RESISTOR 100K 1% SMD 0603 1 R612
..2 RS22K110F03 RESISTOR 22.1K 1% SMD 0603 2 R4A,4B
..2 RS330K10F03 RESISTOR 330K 1% SMD 0603 1 R742
..2 RS510K10F03 RESISTOR 510K 1% SMD 0603 1 R611
..2 SC0304RINI Screw M3X4 PPN 2 (VR922)
..2 SWDC11B20214G9 Switch Rotatiomal Encoder 20Pu 2 E800,801
..2 SWSFKHVBD3515 Switch Tact 5mm 100g Horizonta 24 SW800~809,813,814,819,821~831
..2 SWSSSF022NA1-YN Switch Side 2P2T 1 SW832
..2 TE10200602 6P CONNECTOR 1 (TE700)
..2 TE682000501 Pin Header 90° Pitch:2.0mm Single Row 5 4 (TE600~602,900)
..2 TR2SK1828 Mosfet N-CH 20V MAIN 2-Pin 2 Q702,703
..2 UH160808T-601Y CAPACITOR 5 L700~702,R625,628
..2 UH201209T-601Y BEAD 600Ω @100MHz 2A ±25% 08 3 L604~606
..2 UHACM2012900-2P Chock 90Ω 0.4A 2.0X1.2mm 3 L600~602
..2 UHBLM18HD102SN1 Bead 1100Ω 1GHZ 50mA 0603 1 L603
..2 VRR10312501 Potentiometer Rotary Volume:10 5 VR900,904,908,912,916
..2 VRR50312501 Potentiometer Rotary Volume:50 1 VR927
..2 VRR50312502 Potentiometer Rotary Volume:50 13 VR901~903,905~907,909~911,913~915,917
..2 VRS10303011 Potentiometer Slide Volume:10K 4 VR923~926
..2 VRS10304541 Potentiometer Slide 10KSB 45mm 1 VR922
..2 VRS50304532 Potentiometer Slide Volume:50K 4 VR918~921
..2 XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamen 1 X601
..2 XTM12000X801 Crystal Oscillator 12MHz 3.2*2 1 X600
0.1 TWPC15C03901 Control PCB Assembly-A 1 42
..2 AL2-51-4401 TRANSISTOR 2N4401 NPN 2 Q1A,1B
..2 AL2-51-4403 TRANSISTOR 2N4403 PNP 2 Q400,401
..2 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 5 C505~509
..2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 6 C410,411,419,421,423,425
..2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 16
C1A,1B,147,400,401,413,415,418,420,422,4
24,500~504
..2 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 3 C412,414,416
..2 CS470J5003NPO CCAP SMD 47pF/50V 5% 0603 NPO 1 C406
..2 DIEN1N4148WSM Diode SMD 2 D406,408
..2 DIPH574 Photo Sensor 2 SEN1A,1B
..2 DISDBAT54CSM Zener Diode BAST54C 12 D400~405,407,409~413
..2 ECS10716D Capacitor Electrolytic 100uF/16V D type 1 EC400
..2 FCN1T1004001
FCN Down Touch zif smd Pitch 1.0mm 40Pin
1 FCN400
..2 IC74HCT595D IC 74HCT595D 5 IC500~504
..2 IC74LVC1G14DBVR IC SN74LVC1G14DBVR 1 IC403
..2 IC74LVC1G17SE-7 IC 74LVC1G17SE-7 2 U1A,1B
..2 LDJ1M1F1BB7R4S3 Liquid-emitting Diode Red/Green/Blue SMD 8 LD500~507
..2 LDKPT-1608CGCK Liquid-emitting Diode Green SMD 2 LD524,525
..2 LDKPT1608VRYX1F LED Yellow SMD 0603 120° 2 LD520,521
..2 LDLTST-C190KSKT Liquid-emitting Diode Amber SMD 6 LD508,511,513,515,518,519
..2 LDLTST-C193TBKT Liquid-emitting Diode Blue SMD 5 LD509,510,512,514,522
..2 LDLTST-C193TGKT Liquid-emitting Diode Green SMD 2 LD516,517
..2 LDLTW-C191TS5 Liquid-emitting Diode White SMD 1 LD523
..2 PC15C039 Control PCB-A 1 -
..2 RS001M10F03 RESISTOR 1M 1% SMD 0603 1 R437
..2 RS010010F03 RESISTOR 100Ω 1% SMD 0603 5 R542~546
..2 RS010K10F03 RESISTOR 10K 1% SMD 0603 3 R3A,3B,436
..2 RS022010F03 RESISTOR 220Ω 1% SMD 0603 2 R540,541
..2 RS033010F03 RESISTOR 330Ω 1% SMD 0603 8 R501,504,507,510,513,516,519,522

Reloop TOUCH Specifications

General

MIDI	24 bit
Platter size	5 \
Product color	Black
Scratcher type	Digital Vinyl System (DVS) scratcher
Platter backlight	Yes
Number of drum pads	16
USB direct playback	-
Built-in optical drive	No
Number of mixer channels	2 channels
Number of scratcher platters	2
Headphone outputs	1
Power supply type	DC
Display type	LED
Display diagonal	7 \

Weight and Dimensions

Depth	377 mm
Width	594 mm
Height	43 mm
Weight	3700 g
