Page #13 background imageLoading...
Page #13 background image
..2 RS033210F03 RESISTOR 332Ω 1% SMD 0603 2 R2A,2B
..2 RS036010F03 RESISTOR 360Ω 1% SMD 0603 20
R502,505,508,511,514,517,520,523,525~52
8,530~535,538,539
..2 RS043010F03 RESISTOR 430Ω 1% SMD 0603 4 R524,529,536,537
..2 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 2 R440,441
..2 RS056210F03 RESISTOR 562Ω 1% SMD 0603 2 R1A,1B
..2 RS068010F03 RESISTOR 680Ω 1% SMD 0603 8 R500,503,506,509,512,515,518,521
..2 RS068K10F03 RESISTOR 68K 1% SMD 0603 1 R434
..2 RS22K110F03 RESISTOR 22.1K 1% SMD 0603 2 R4A,4B
..2 RS330K10F03 RESISTOR 330K 1% SMD 0603 1 R435
..2 SWDC11B20214G9 Switch Rotatiomal Encoder 20Pu 1 E400
..2 SWSFKHVBD3515 Switch Tact 5mm 100g Horizonta 15 SW400~402,406,407,412~414,416~422
..2 TE10200602 6P CONNECTOR 1 (TE400)
..2 TR2SK1828 Mosfet N-CH 20V MAIN 2-Pin 2 Q402,403
..2 UH160808T-601Y CAPACITOR 3 L400~402
..2 VRS10303011 Potentiometer Slide Volume:10K 4 VR1~4
0.1 TWPC15C05301 Main PCB Assembly 1
..2 PC15C053 Main PCB 1
..2 TWPC15C053A01 Main PCB Assembly 1 53
...3 AL2-51-0140 Schottky Barrier Rectifiers Diode 1 D108
...3 AL2-51-4401 TRANSISTOR 2N4401 NPN 2 Q101,103
...3 AL2-54-6306 Mosfet FDC6306P P-CH 1 Q102
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 14
C314,315,324,326,329,332,338,344~346,35
0,351,353,354
...3 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 2 C316,317
...3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 3 C100,103,108
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 39
C1~5,101,102,105~107,109~116,118,121,3
19,322,323,325,328,331,334~336,339~341,
343,349,356~359,361
...3 CS106K1606X7R CCAP SMD 10uF/16V 10% 1206 X7R 8 C320,321,327,330,337,342,348,360
...3 CS222K5003X7R CCAP SMD 2.2NF/50V 10% 0603 X7R 4 C333,347,352,355
...3 CS332K5003X7R CCAP SMD 3.3nF/50V 10% 0603 X7R 2 C104,120
...3 CS820J5003NPO CCAP SMD 82pF/50V 5% 0603 NPO 1 C119
...3 DIEN1N4148WSM Diode SMD 2 D101,102
...3 DISDB540C-13-F Schottky Barrier Rectifier Diode 2 D100,109
...3 DISDMBRA340T3G Shottky diode DISDMBRA340T3G S 4 D103,105~107
...3 DITVSNUP2201SM Transient Voltage Suppressol Diode 1 D104
...3 ECS10625BLE ECAP Low ESR 10UF/25V 4*5.4mm 5 EC102,103,106,109,112
...3 ECS22616C Capacitor Electrolytic 22uF/16V C type 2 EC108,111
...3 ECS22716E Ecap 220uF/16V 6.3*7.7mm SMD 2 EC107,110
...3 ECS22725FLE ECAP LOWESR 220/25V 8*10MM SMD 3 EC105,113,116
...3 ECS22735GLE ECAP LOW ESR 220UF/35V 10x10.3 1 EC115
...3 ECS47625D ECAP 47uf/25v 6.3*5.3mm SMD 6 EC314,315,317~319,321
...3 ECS47725GLE ECAP LOWESR 470UF/25V 10*10MM 4 EC100,101,104,114
...3 FCN1T1002201 FCN Down Touch 90° Pitch=1.0mm 1 FCN300
...3 ICAK4346 IC AK4346 24Bit 6channel DAC 1 IC309
...3 ICEML3230 IC EML3230 1 IC100
...3 ICEMP8110 IC EMP8110 1 IC102
...3 ICLM1086ADJ IC LM1086-ADJ 1 IC101
...3 ICMC33078DR2G IC MC33078DR2G 3 IC307,308,310
...3 ICNJM4556AM IC NJM4556AM 2 IC311,312
...3 ICTLV70033DDCT IC TLV70033DDCT 1 IC306
...3 ICTPS54140DGQ IC TPS54140DGQ 1 IC103
...3 JK0KUSBXHTBS1NO B-TYPE USB Jack 90° (Orange) 1 USB100
...3 JKDJ-0702B-020 DC Base 2.0MM 1 J100
...3 JY6317-02-030 Earphone base W/NUT 2 JK301,302
...3 MT11044128 Fixed Plate 1 (M1)
...3 RJ2008HP-11F15A 2PIN RCA JACK 1 JK300
...3 RS000004J06 RESISTOR 0Ω 5% SMD 1206 1 R122
...3 RS000010J03 RESISTOR 0Ω 5% SMD 0603 1 R111
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 10 R329,334,345,351,370,371,373~375,377
...3 RS001M10F03 RESISTOR 1M 1% SMD 0603 2 R113,114
