Reloop TOUCH Service Manual

...3 RS003310F03 RESISTOR 33Ω 1% SMD 0603 2 R339,341
...3 RS010K10F03 RESISTOR 10K 1% SMD 0603 24
R108,112,120,124,130,326~328,332,335,34
0,342~344,346,349,352~355,358,362,363,3
66
...3 RS011K10F03 RESISTOR 11K 1% SMD 0603 1 R105
...3 RS012110F03 RESISTOR 121Ω 1% SMD 0603 1 R110
...3 RS012K10F03 RESISTOR 12K 1% SMD 0603 9 R103,324,325,331,336,338,348,357,365
...3 RS01K210F03 RESISTOR 1.2K 1% SMD 0603 1 R337
...3 RS030010F03 RESISTOR 300Ω 1% SMD 0603 1 R115
...3 RS03K910F03 RESISTOR 3.9K 1% SMD 0603 4 R330,347,356,364
...3 RS04K710F03 RESISTOR 4.7K 1% SMD 0603 1 R129
...3 RS051K10F03 RESISTOR 51K 1% SMD 0603 1 R102
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 5 R101,333,350,372,376
...3 RS150K10F03 RESISTOR 150K 1% SMD 0603 1 R121
...3 RS220K10F03 RESISTOR 220K 1% SMD 0603 1 R127
...3 RS47K510F03 RESISTOR 47.5K 1% SMD 0603 2 R106,107
...3 RS698K10F03 RESISTOR 698K 1% SMD 0603 1 R128
...3 SWSPPJ22ME04 Switch Push 2P2T Dual Row Lock 1 SW100
...3 TE10200502 5P CONNECTOR 1 (TE100)
...3 TE622000501 5P CONNECTOR 1 (TE301)
...3 TE622000901 9P CONNECTOR 1 (TE302)
...3 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 4 Q305~308
...3 TRMMBT2907ALT1 TRANSISTOR MMBT2907ALT1 1 Q100
...3 UHDRRI125-101M Inductor, 100UH±20% 1.3A SMD 2 L103,105
...3 UHPIC1207-221M Inductor SMD 220UH 2 L102,104
...3 UHPID1207-680M Inductor 68uH±20% 3A SMD 1 L101
...3 UHSQD105T-751 Common Inductor 700Ω ±35% 10.3X8mm 1 L100
..2 TWPC15C053B01 HeadPhone PCB Assembly 1 56
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 4 C500~503
...3 ECS47725GLE ECAP LOWESR 470UF/25V 10*10MM 2 EC500,501
...3 JK-3537 3.5mm Phone Jack 9P 90° DIP 1 JK500
...3 JY6317-02-030 Earphone base W/NUT 1 JY500
...3 RS001K10F03 RESISTOR 1K 1% SMD 0603 2 R501,504
...3 RS002210F03 RESISTOR 22Ω 1% SMD 0603 2 R500,503
...3 RS100K10F03 RESISTOR 100K 1% SMD 0603 2 R502,505
...3 TE622000501 5P CONNECTOR 1 (TE500)
...3 TR2SD2114KSM TRANSISTOR 2SD2114K NPN 2 Q500,501
..2 TWPC15C053C01 MIC PCB Assembly 1 59
...3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 4 C506~509
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 4 C504,505,510,511
...3 ECS10625BLE ECAP Low ESR 10UF/25V 4*5.4mm 2 EC502,503
...3 ECS47625D ECAP 47uf/25v 6.3*5.3mm SMD 3 EC504~506
...3 ICMC33078DR2G IC MC33078DR2G 1 IC500
...3 JY6317-02-130 MIC JACK 1 JY501
...3 RS010010F03 RESISTOR 100Ω 1% SMD 0603 2 R507,508
...3 RS051K10F03 RESISTOR 51K 1% SMD 0603 2 R506,509
...3 TE622000501 5P CONNECTOR 1 (TE502)
...3 TE622000901 9P CONNECTOR 1 (TE501)
...3 VRR50303007 VR 50KA 1 VR500
..2 TWPC15C053D01 Pitch PCB Assembly-L 1 57
...3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 1 C602
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 2 C600,601
...3 LDLTST-C191KRKT Liquid-emitting Diode Red SMD 0603 1 LD600
...3 RS056010F03 RESISTOR 560Ω 1% SMD 0603 1 R600
...3 TE10200602 6P CONNECTOR 1 (TE600)
...3 VRS10306024 Potentiometer Slide 10KSB Trau 1 VR600
..2 TWPC15C053E01 Pitch PCB Assembly-R 1 58
...3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 1 C702
...3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 2 C700,701
...3 LDLTST-C191KRKT Liquid-emitting Diode Red SMD 0603 1 LD700

Reloop TOUCH Specifications

General

MIDI	24 bit
Platter size	5 \
Product color	Black
Scratcher type	Digital Vinyl System (DVS) scratcher
Platter backlight	Yes
Number of drum pads	16
USB direct playback	-
Built-in optical drive	No
Number of mixer channels	2 channels
Number of scratcher platters	2
Headphone outputs	1
Power supply type	DC
Display type	LED
Display diagonal	7 \

Weight and Dimensions

Depth	377 mm
Width	594 mm
Height	43 mm
Weight	3700 g
