NO. CONTROL / ELEMENT VIRTUALDJ
9 LOAD Load selected track from library to deck. Instant Doubles by double click
SHIFT + 9 VIEW Switches between the various touch screen views.
10 TRAX (turn) Scrolls through items in currently focused list / selection
10 TRAX (press) Moves focus to next area of library or panel
11 BACK Moves focus to previous area of library or panel
12 MASTER VOL Controls master output volume
13 PHONES VOL Adjusts cue volume
14 CUE MIX Blends between cue and master signals for pre-listening
15 PLAY/PAUSE Activate playback / pause
SHIFT + 15 STUTTER Triggers the temporary cue and the playhead will continue from that point.
16 CUE
During playback: Track will return to temporary cue point and stop.
During pause: A new temporary cue point will be set at the current position. When the cue button is pressed again, the tem-
porary cue will be playback as long as cue is held.
SHIFT + 16 GO TO BEG
When pressed, playhead returns to the beginning of the track.
Loads previous track when pressed within the 1sec of a track.
17 SYNC Activates sync (tempo & beat)
SHIFT + 17 MASTER For more information refer to item 6 of the touch screen functions.
18 MODE
19 XCODER For more information refer to item 10-12 of the touch screen functions.
20 SHIFT Enables 2nd layer functions as indicated on the controller.
21 PITCH BEND < Lowers pitch for as long as the button is being held.
SHIFT + 21 PITCH RANGE - For more information refer to item 8 of the touch screen functions.
22 PITCH BEND > Increases pitch for as long as the button is being held.
SHIFT + 22 PITCH RANGE + For more information refer to item 8 of the touch screen functions.
23 PITCH Determines tempo of track
23a PITCH LED Lit when PITCH-fader is in 0% position
24 DECK Switches deck related controls between deck 1/3 and deck 2/4.
25 SLIP
Enables Slip-mode on or off. When Slip-mode is active after various actions (e.g.: cue points or scratches) playback will conti-
nue at the point to where it would have been if you had not done anything.
SHIFT + 25 VINYL Toggle between vinyl (touch sensitive scratch) and jog mode (only pitch bend) for platter. (no. 38a)
26 JOG-WHEEL
When Jog Touch (SHIFT + no. 25) is enabled, touching platter will hold playhead (or scratch). Also pitch bend is possible by
nudging the rim. When Jog Touch is off (SHIFT + no. 25), turning the platter will pitch bend the deck only.
SHIFT + 26 JOG SKIP Performs a needle search/fast scroll through track
27 FX1 ON For more information refer to item 18-39 of the touch screen functions.
28 FX1 PARAM For more information refer to item 18-39 of the touch screen functions.
29 FX2 ON For more information refer to item 18-39 of the touch screen functions.
30 FX2 PARAM For more information refer to item 18-39 of the touch screen functions.
31 FX3 ON For more information refer to item 18-39 of the touch screen functions.
32 FX3 PARAM For more information refer to item 18-39 of the touch screen functions.
33 VIDEO FX ON For more information refer to item 18-39 of the touch screen functions.
34 VIDEO FX PARAM For more information refer to item 18-39 of the touch screen functions.
35 PAD MODE For more information refer to item 40-43 of the touch screen functions.
36 Performance PADs For more information refer to item 40-43 of the touch screen functions.
37 PARAM For more information refer to item 40-43 of the touch screen functions.
38 HEADPHONES OUT 3,5 mm & 6,3 mm Output
39 MIC INPUT Microphone Input 6,3 mm. The audio signal from the microphone is routed directly to the master output.
40 MIC VOL Microphone Input GAIN adjust
41 POWER Power On/Off. Device requires external power supply.
42 PSU Power supply unit connection
43 USB INPUT USB connection to PC/MAC
44 MST OUT (JACK) Master Volume Output (JACK)
45 MST OUT (RCA) Master Volume Output (RCA)
46 KENSINGTON Kensington lock connection
