TECHNICAL DATA
TECHNICAL SPECIFICATIONS
Inputs: ............................... Mic 6.3 mm jack
Outputs: ............................ Master 6.3 mm jack (balanced)
................................. Master RCA (unbalanced)
................................. Headphones 6.3/3.5 mm jack
Interfaces: ......................... USB for audio, video and touch transmission
Power supply unit: .............. 12V/3A
Dimensions: ....................... 594 x 377 x 43 mm
Weight: .............................. 3,7 kg
MEASUREMENT ITEM MEASUREMENT SIGNAL MICROPHONE VR SPECIFICATION REMARKS
OUTPUT LEVEL
MASTER OUT(RCA)
MIN
2.0 ± 0.2 V
- 0dB
- 1kHz Sine Wave from PC
- No Microphone lnput
MASTER OUT(TRS) 2.0 ± 0.2 V
HEADPHONE MIN 1.2V ± 0.2V
- 0dB
- 1kHz
- No audio from PCC
- No Microphone lnput
- Headphone (load32Ω)
MIC (RCA) MAX 1.0V ± 0.2V
- No audio from PC
- + 3mV Vrms Microphone lnput
- 50-ohm UNbalanced AP audio generator output
S/N NOISE LEVEL
MASTER OUT(RCA)
MIN
Less than -80dBr
- 0dB
- 1kHz Sine Wave from PC
- No Microphone lnput
MASTER OUT(TRS) Less than -80dBr
HEADPHONE MIN Less than -80dBr
- 0dB
- 1kHz Sine Wave from PC
- No Microphone lnput
THD + N
MASTER OUT(RCA)
MIN
Less than 0.05%
- 0dB
- 1kHz Sine Wave from PC
- No Microphone lnput
MASTER OUT(TRS) Less than 0.05%
HEADPHONE MIN Less than 0.05%
- 0dB
- 1kHz Sine Wave from PC
- No Microphone lnput

Table of Contents

Other manuals for Reloop TOUCH

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Reloop TOUCH and is the answer not in the manual?

Reloop TOUCH Specifications

General IconGeneral
MIDI24 bit
Platter size5 \
Product colorBlack
Scratcher typeDigital Vinyl System (DVS) scratcher
Platter backlightYes
Number of drum pads16
USB direct playback-
Built-in optical driveNo
Number of mixer channels2 channels
Number of scratcher platters2
Headphone outputs1
Power supply typeDC
Display typeLED
Display diagonal7 \
Weight and Dimensions IconWeight and Dimensions
Depth377 mm
Width594 mm
Height43 mm
Weight3700 g
