INSTALLATION INSTRUCTIONS
1. * Locate the dispenser indoors on a level counter top, unpack 4 legs and install them into the threaded
holes provided in the bottom of the unit.
2. Connect 3/4”IPS (or equal) drain line to the 3/4”threaded drain connections at the lower rear of the unit.
This line must pitch downward
to an open drain, and must contain no traps, or im proper drainage will
result.
3. Clean the hopper interior (see cleaning instructions).
4. Connect the power cord to a 120 volt, 60 Hz. 3-wire grounded receptacle.
Unit is now ready for operation.
NOTE: *Figure 1, page 6 provides mounting template for those who desire to mount dispensers on a
counter.
