Remcor TJ45 - Figure 1. Mounting Templates

90614 6
TJ45
TJ90
15 7/8-IN
12 5/8-IN 1 5/8-IN
18 9/16-IN
21 25/32-IN
15/8-IN
15/8-IN18 3/4-IN
22-IN
24 1/2-IN
27 23/32-IN
15/8-IN
OUTLINE OF
UNITS
3/4-IN DIA.
FIGURE 1. MOUNTING TEMPLATES
