REMET CNC RS80 - 3 Specification of the Device

REMET CNC TECHNOLOGY SP. Z O.O.
Page 8 of 51
Manufacturer of machinery and equipment, machining
3. SPECIFICATION OF THE DEVICE
Technical parameters of chipper:
Model RS-80 RS-100 RS-120+PTO
RS-100
OFF-ROAD
RS-120
OFF-ROAD
Inner width [mm]
180 180 180 180 180
Distance between
streams [mm]
80 100 120 100 120
Diameter of gears [mm]
150 180 200 180 200
Case thickness [mm]
20 20 20 20 20
Gasoline engine
4-stroke, OHV, air-cooled
Combustion engine power
[kW]
3.8 - 4.4
8.2 – 9.6 8.2 – 9.6 8.2 – 9.6 8.2 – 9.6
9.1 - 11 9.1 - 11 9.1 - 11 9.1 - 11
Minimum / Recommended
PTO drive power [kW]
--- --- 30 --- ---
Max. cutting diameter of
fresh softwood [mm] *
50 80 80/100 80 90
Max. cutting diameter of
fresh hard wood [mm] *
45 60 70/90 60 80
Max. cutting diameter of
dry hardwood [mm] *
40 50 60/70 50 70
Cutting length
wood chips [cm]]
4 knives:9-15
6 knives:5-12
4 knives:9-18
6 knives:7-14
6 knives:8-15
8 knives:5-10
4 knives:9-18
6 knives:7-14
6 knives:8-15
8 knives: 5-10
Weight [kg]
170 225 270 340 420
* The maximum diameter of shredded branches depends on the type of wood
and the conditions when cutting the material. For hardwood (eg oak / beech),
the maximum cutting diameter will be less than soft wood (eg pine, spruce). In
the case of dry or gnarled wood, the maximum cutting diameter will also be
reduced
