REMIS REMIfrontII-S - C. Operating Information

REMIfrontII-S User information
Issue: 34/2005 We reserve the right to make changes Page 4/5
Step 4: (Mount the side system)
B34:
Insert frame and
press against door.
B35:
Screw on frame.
(6x screws
3.5x19).
D. Operating information
Front system:
C1:
Push button up to
unlock front blind.
C2:
Pull handles from
left and right
towards the middle
of the windscreen.
C3:
Bring handles
together in the
middle, magnetic
catch locks blinds
automatically.
Side system:
C4:
To open:
Release handle
from rest position
by tilting and
pulling lightly.
To close:
Latch in handle by
pressing onto
frame.
C5:
Bring handle up to
stop rail, magnetic
catch locks
automatically.
C6:
To open:
Release handle
from rest position
by tilting and
pulling lightly.
To close:
Latch in handle by
pressing onto
frame.
C7:
Bring handle up to
stop rail, magnetic
catch locks
automatically.
C4
C5
C6 C7
