REMKO KWL 130 - Spare Parts Lists

Spare parts list
No. Designation
KWL
130
KWL
160
KWL 180 KWL 220
KWL
130 H
KWL
160 H
KWL 180
H
KWL 220
H
1 Operating panel, compressor element RAL 1110001 1110001 1110002 1110002 1110001 1110001 1110002 1110002
1 Operating panel, compressor element INOX 1110760 1110760 1110761 1110761 1110760 1110760 1110761 1110761
2 Condenser protective grid RAL 1110003 1110003 1110004 1110004 1110003 1110003 1110004 1110004
2 Condenser protective grid INOX 1110762 1110762 1110763 1110763 1110762 1110762 1110763 1110763
3 Condenser protective grid RAL 1110005 1110005 1110006 1110006 1110005 1110005 1110006 1110006
3 Condenser protective grid INOX 1110764 1110764 1110765 1110765 1110764 1110764 1110765 1110765
4 Fan panel RAL 1110007 1110007 1110008 1110008 1110007 1110007 1110008 1110008
4 Fan panel INOX 1110766 1110766 1110767 1110767 1110766 1110766 1110767 1110767
5 Side panel RAL 1110009 1110009 1110010 1110010 1110009 1110009 1110010 1110010
5 Side panel INOX 1110768 1110768 1110769 1110769 1110768 1110768 1110769 1110769
6 Side panel RAL 1110011 1110011 1110012 1110012 1110011 1110011 1110012 1110012
6 Side panel INOX 1110770 1110770 1110771 1110771 1110770 1110770 1110771 1110771
7 Roof panel RAL 1110013 1110013 1110014 1110014 1110013 1110013 1110014 1110014
7 Roof panel INOX 1110772 1110772 1110773 1110773 1110772 1110772 1110773 1110773
8 Finned condenser 1110017 1110018 1110019 1110019 1110540 1110541 1110542 1110543
9 Condenser fan 1110020 1110020 1110021 1110021 1110020 1110020 1110021 1110021
10 Evaporator 1110022 1110022 1110023 1110023 1110022 1110022 1110023 1110023
11 SANYO compressor 1110024 1110025 1110026 1110027 1110024 1110025 1110026 1110027
11 Danfoss-Maneurop compressor - - - 1106715 - - - 1106715
12 Expansion valve, cpl. 1110028 1110029 1110029 1110030 1110028 1110029 1110029 1110030
13 Diaphragm expansion vessel 1110036 1110036 1110037 1110037 1110036 1110036 1110037 1110037
14 Circulation pump 1110033 1110033 1110033 1110033 1110033 1110033 1110033 1110033
15 Differential pressure switch 1110034 1110034 1110035 1110035 1110034 1110034 1110035 1110035
16 Controller covering 1110051 1110051 1110051 1110051 1110051 1110051 1110051 1110051
Spare parts (not illustrated)
Safety valve 1110038 1110038 1110038 1110038 1110038 1110038 1110038 1110038
Control system protection switch 1110039 1110040 1110040 1110040 1110039 1110040 1110040 1110040
Compressor protection switch 1110041 1110042 1110042 1110042 1110041 1110042 1110042 1110042
Circulation pump fuse 1110043 1110043 1110043 1110043 1110043 1110043 1110043 1110043
Phase sequence relay 1110044 1110044 1110045 1110045 1110044 1110044 1110045 1110045
IChill adaptive controller 1110046 1110046 1110046 1110046 1110046 1110046 1110046 1110046
IChill adaptive controller, programmed 1110047 1110048 1110049 1110050 1110544 1110545 1110546 1110547
Fan controller 1110052 1110052 1110054 1110054 1110052 1110052 1110054 1110054
Transformer 1110053 1110053 1110053 1110053 1110053 1110053 1110053 1110053
Sensor 1110055 1110055 1110055 1110055 1110055 1110055 1110055 1110055
Compressor protection 1110056 1110056 1110057 1110058 1110056 1110056 1110057 1110058
Circulation pump protection 1110059 1110059 1110059 1110059 1110059 1110059 1110059 1110059
Equipment cladding, set 1110015 1110015 1110016 1110016 1110015 1110015 1110016 1110016
High pressure monitor 1110031 1110031 1110031 1110031 1110031 1110031 1110031 1110031
Low pressure monitor 1110032 1110032 1110032 1110032 1110032 1110032 1110032 1110032
Condenser, condenser fan 1110061 1110061 1110062 1110062 1110061 1110061 1110062 1110062
Reversing valve, valve body - - - - 1110548 1110549 1110550 1110551
Reversing valve, coil - - - - 1110552 1110553 1110554 1110555
Pressure transducer winter pressure controller 1106361 1106361 1106361 1106361 1106361 1106361 1106361 1106361
When ordering spare parts, please state the computerised part no. and unit number (see identification plate) !
