Remote Control RCEL Series User Manual

- 7 -
www.rotork.com www.remotecontrol.se
Setting Mode
Marking Name Spec
a Set Actuator Setting
b Position
Actuator Position
Display
c Manu Setting Mode
Place the selector switch in “OFF” position and press the open and close button for over 2 seconds to enter the
setting mode.
CLOSE
OPEN
● Open & Close Press ●
a
c
b
STOP
1 sec
STOP
2 sec
STOP
2 sec
CLOSE
1 sec
STOP
2 sec
“HOLD” Setting
“INCHING” Setting
CLOSE
1 sec
OPEN
1 sec
STOP
1 sec
STOP
2 sec
STOP
2 sec
CLOSE
1 sec
STOP
2 sec
“CLOSE” Setting
“OPEN” Setting
CLOSE
1 sec
OPEN
1 sec
STOP
2 sec
“STOP” Setting
CLOSE
1 sec
OPEN
1 sec
CLOSE
1 sec
OPEN
1 sec
VOID
CLOSE
1 sec
OPEN
1 sec
VOID
