FUEL MIXTURE
Air intake
12
12-5
REMOVAL
Put the vehicle on a two post lift.
Disconnect the battery.
Remove:
– the lower engine cover,
– the air exchanger/damper unit pipe after
disconnecting the electrics.
Place hose pliers on the oil tank/power assisted
steering pump return pipe and disconnect the pump.
Separate the power steering reservoir without
disconnecting the pump and move it on the side
member.
Remove:
– the turbocharger/exchanger air pipe mounting bolts
from the cylinder head,
– the stiffening bracket (1) between the damper unit
and the power assisted steering pump mounting,
– the exhaust gas recirculation pipe (2) and the seals.
Plan for the replacement of the pipe and the seals
when refitting.
Disconnect the exhaust gas recirculation control
solenoid valve connector.
15853M1
