MANUAL GEARBOX
Lubricants
21
21-3
Lubricants
OIL CAPACITY :
– Maximum: 2.8 l
– Minimum: 2.3 l
OIL LEVEL
The oil level is adjusted using a locally manufactured
dipstick, inserting into the oil filler hole (2) (see
Technical Note 2579A).
To check the level it is necessary to remove the left
hand front wheel and the left hand wheel arch cover.
The oil can also be changed and refilled with the
recommended quantity.
1 Drain plug
2 Fuel filler cap
WARNING: the fuel filler cap (2) should not be used to
check the level by overfilling; using too much oil may
damage the seals and overheat the oil.
Marks to graduate:
– B: 22 ± 0.5 mm
– C: 30 ± 0.5 mm
95321M
