STARTING - CHARGING
Alternator
16
16-2
REMOVAL
Put the vehicle on a 2 post lift.
Disconnect the battery and the electrical connections
on the alternator and the air conditioning compressor.
Remove:
– the front right wheel,
– the right-hand wheel arch cover,
– the lower engine cover,
– the bumper,
– the windscreen washer tank,
– the air exchanger/throttle body unit pipe after
disconnecting it,
– the accessories belt (see method on page 11-1),
– the accessories belt pulley.
