STARTING - CHARGING
Alternator
16
16-3
Undo the four air conditioning compressor mounting
bolts and allow this to hang by its pipes.
Undo and remove the lower mounting bolt on the
alternator; undo the upper bolt without removing it,
On the right-hand side below, remove the vertical
engine tie-bar mounting bolt.
Undo without removing the pre-catalytic converter
mountings on the exhaust pipe.
Remove the upper mounting bolt on the alternator by
manually lifting the engine and transmission assembly
forwards; the bolt passes just above the right hand
side member.
REFITTING
Refitting is the reverse of removal.
