AIR VENTS (air outlets)
1 - left-hand front window demister
2 - left-hand side air vent
3 - windscreen demister outlets
4 - Centre air vents
5 - control panel
6 - Right-hand side air vent
7 - Right-hand side window demister
vent
8 - Footwell heater outlet
