5.03
EMERGENCY SPARE WHEEL (continued)
To wind a wheel back up
To carry out this operation, the
cable must be unwound.
If the cable has been wound back up
on its own, unwind it again as
follows:
- pull the handle to unwind the
cable,
- press the button located under
handle 5 to hold the unwound
cable, then guide it down,
- recover the cable from underneath
the vehicle.
You may refit the wheel.
After changing a wheel, position the
replaced wheel on support 9,with
the valve facing the ground.
Depending on the vehicle,
reposition the chock 7.Clipthe
cable 6 into its housing 8 then push
the wheel under the luggage
compartment (with tab 10 at the rear
of the vehicle).
Make sure that no one
has their fingers close to
the cable when you move
the handle: risk of injury
Position yourself behind the vehicle
and pull handle 5 to raise the wheel
until it is anchored under the
vehicle.
