REAR BENCH SEAT: functions
The seat and the seatback may be
folded down in one or two parts to
allow bulky objects to be carried.
You must fold the seat base before
folding the seatback.
To fold away the seat
Lift the front of the bench seat
cushion A as far as possible.
Where the bench seat is in one
section, check that the two sides of
the seat base are correctly locked.
Then lift the rear section 1 of the
cushion and turn the seat base to
position it against the front seats.
For safety reasons, carry
out any adjustments
when the vehicle is not
being driven.
To fold down the seatback
Remove the rear headrests (if
fitted).
Ensure that the front seats are far
enough forward.
Place the seat belts in their guides B.
Press button 2 and lower the
seatback C.
Before moving the seatback,
place the seat belt in the belt
guide A so as not to damage it.
