QUICKSHIFT GEARBOX
Gear lever 1
- This allows you to shift directly
from first gear to reverse gear, to
select reverse gear and neutral and
to change gear in manual mode.
- It also allows you to switch
between manual and automatic
modes at any time, with the engine
switched on and reverse gear
engaged, by moving the lever to
the left.
Note: the selector lever
automatically returns to the centre
position after use.
Display
2 automatic mode
3 gear display
4 brake pedal depressed indicator
light
5 snow mode
The gear selected (1, 2 etc., 5, N, R)
is indicated on the instrument panel
display. In automatic mode, A is
displayed.
Paddles 6
Like the lever, they allow you to
change gear:
- while driving,
- while stopped with the engine off
and the ignition on.
The left-hand switch allows you to
change down.
The right-hand switch allows you to
change up.
Neutral and reverse gears are not
accessible using the paddles, unless
there is an operating fault (refer to
the end of the information on
“Quickshift gearbox: operating
fault).
